100m Remote Natural Gas TDLAS Methane Detector Bluetooth WIFI Battery Powered

Bluetooth WIFI 100m Remote TDLAS Laser Methane Detector for Natural City Gas Pipeline Leak Inspection

Description:

The remote laser methane detector is Intrinsically Safety instrument with a rating of Class I, Division II, which allows operators to use it indoors and within potentially hazardous environments such as compressor stations. The field rugged design operates under a variety of field conditions, can detect up to 350 feet away allowing operators to safely survey in areas that may be difficult to reach such as busy roadways, yards with dogs, fenced off areas, compressor stations, overhead piping and other hard to access places.

With a range of up to 100 meters the remote methane leak detector is able to measure from 5 ppm•m up to high concentrations to enable fast remote leak detection during leak surveys. The TDLAS technology is based on the principle of absorption infrared spectroscopy using a diode laser with tunable frequency. Together with advanced algorithm, it can display the gas concentration at ppm•m.

THE ADA software application meets the growing demand for tracking and traceability. With the L10M remote laser methane leak detector, the user can keep their eyes on the target while the ADA software application captures streaming data. The app logs date, time, GPS coordinates, and gas measurements, and sessions can be exported in multiple formats from the phone/tablet. The software built-in picture capture feature association readings with pictures or reports of corrosion issues.

Laser Absorption Spectroscopy (TDLAS):

The core of these remote laser gas detection systems is often TDLAS (Tunable Diode Laser Absorption Spectroscopy). This remote laser gas detector technology emits a laser beam and measures how much of the laser light is absorbed by methane molecules in the air. The laser beam of the Remote laser methane leak detector is transmitted towards the target. Once reached, the beam is then reflected back to the detector for analysis. The results show on
the display screen immediately.

Advantages:

The remote laser methane leak detector range offers a 0.1 second response to detected methane, over an expected 10-year laser sensor life. User settable audible alerts allow an operator to quickly scan for methane over a wide area, without having to use a reflector. From Natural gas pipeline to biogas, fast leak detection means improved safety and environmental impact and increased profitability through reduction of gas loss and tighter management of infrastructure maintenance.

Parameters:

Characters:

● Remote methane leak detection
● Leak survey report generated
● Leak detection and repair (LDAR)
● Surface emissions monitoring
● Rapid Response less 0.1s

● Long distance >330 feet (100 meters) methane leak detection
● Sensitive to 5ppm•m
● Audible and visual alarms
● Intrinsically safety laser gas detector
● No warm up or cool down, full day battery life more than 10h

● Free phone App ADA software available

Application:
Natural Gas Leak Detection
Identifying leaks in pipelines, storage tanks, and other natural gas infrastructures.
Environmental Monitoring:
Measuring methane emissions from various sources, including landfills and agricultural activities.
