50m Remote TDLAS Laser Methane Gas Monitoring Devices Pipeline Leak Detection

Iong Range 50m Remote TDLAS Laser Methane Leak Detector Pipeline Inspection Service

Description:

The Remote methane leak detectors (RMLD) are portable, laser-based instruments using Tunable Diode Laser Absorption Spectroscopy (TDLAS) to identify methane from a distance, typically up to 30–200 meters (100–600+ ft). These devices, allow operators to safely survey hard-to-access areas—like busy roads, elevated pipelines, or residential properties—without direct plume contact, offering fast (0.1s) response times and high sensitivity. The L10M laser methane leak detector's competitive price makes it an ideal solution for remote methane detection in hard-to-reach areas. It eliminates the need to access the gas plume directly, climb to elevated areas, access fenced-in properties, and potentially hazardous situations via windows, thereby providing a safe and cost-effective solution.
THE ADA software application meets the growing demand for tracking and traceability. With the L10M remote laser methane leak detector, the user can keep their eyes on the target while the ADA software application captures streaming data. The app logs date, time, GPS coordinates, and gas measurements, and sessions can be exported in multiple formats from the phone/tablet. The phone/table built-in picture capture feature association readings with pictures or reports of leakage inspection.

How It Works:
The laser beam of the Remote laser methane leak detector is transmitted towards the target. As the beam passes through the gas plume, some of the light is absorbed by the methane molecules. A sensor then captures the reflected light, and by analyzing how much is absorbed, the system calculates the methane concentration.The results will show on the display screen immediately.

Key Features:

Methane detection at a distance 165 ft (50 meters)
Small size and light-weight 0.79lbs (360g) easy to carry
Good selectivity, response to Methane only
One-button operation
Sensitivity of 5ppm·m
Fast response, no alarm delay
Visual, audible alarm
Adjustable alarming level between 0-100,000 ppm·m
Low consumption, can be used for continuous operating more than 10 hours
Intrinsically safe design
Self-Test and Calibration Functions
Datalogging Bluetooth connection for instant field reporting, using a mobile ADA software
Suitable for compliance reporting
IP68 enclosure rating

Technical Parameters

Ideal Application:

Remote laser methane Leak detector is primarily used in oil and gas exploration, environmental monitoring, gas pipeline inspection, industrial safety, and emergency response. It helps in methane leak detection, ensuring workplace safety, and preventing environmental hazards in these sectors.

    Natural gas pipeline inspections

Landfill and biogas facility monitoring

Urban utility infrastructure surveys

Emergency response for gas leak detection

Industrial facility safety inspections
